Kohler KD1000 Generator Set

Product Description

General Description

The Kohler KD1000 generator set, diesel, manufactured in France, produces 1000 kVA in emergency mode and 909 kVA in continuous mode, at a frequency of 50 Hz and a speed of 1500 rpm. Supplied voltage: 400 / 230 V.

Engine

The generator is equipped with a KOHLER KD Series engine of 26.97 liters, with a maximum power of 905 kW:

• Number of cylinders: 12
• Fuel: diesel
• Cooling system type: radiator
• Consumption at 100% load: 209.5 l/h
• Consumption at 75% load: 156.9 l/h
• Consumption at 50% load: 104.6 l/h

Alternator

The generator set is equipped with a Kohler alternator with direct coupling, self-excited without brushes, insulation class H, protection degree IP 23, with 3 phases / 4 poles.

Constructive Elements

The generator is equipped with an integrated 1035-liter tank under the chassis, electronic speed regulator, preheating system for the cooling liquid (for easy starting in cold seasons), 12V starting system, rectifier for charging the battery when the generator is not running, alternator for charging the battery during engine operation, and vibration dampers located between the chassis and the engine-alternator assembly.

APM403 Digital Controller

The control panel is easy to use even for unqualified personnel, designed to provide a wealth of details about the operation of the generator set. The controller incorporates dozens of measurement instruments for generator operation, signaling devices for faults and more, command keys, and indicators for various warning messages and correct operation of the entire assembly.

Soundproof Canopy

The soundproof canopy is built from resistant elements, painted to the highest standards. The canopy is equipped with doors that allow easy access to the generator set components for quick and easy interventions. The soundproofing capacity of the canopy is impressive, reducing the noise level to 86 dB at 1 meter and 77 dB at 7 meters.

• Soundproofed generator dimensions: L 6413 mm x W 2160 mm x H 2750 mm.
• Total weight: 8800 kg.

AAR VERSO 200 S – 1600 A source inverter (OPTIONAL)

• Panel dimensions: 1600mm x 606mm x 442mm.
• Protection for ±15% fluctuations in frequency and voltage;
• Protection against phase direction in the network and the group;
• Protection against phase loss.
• LED for signaling the phase of the network and the group;
• LED for the status of the electrical network or group;
• LED for the position of the contactor for the network and the group.

After-Sales Services

In addition to KOHLER generators, Best Tools offers complete services: consultancy, training, warranties, maintenance contracts, a complete range of related equipment, delivery, installation, and commissioning. Best Tools Company technicians are directly trained by KOHLER, regularly participating in training sessions organized in Brest, France. National coverage is ensured by more than 15 mobile service laboratories and by personnel located in key points in Romania. The central service laboratory in Bucharest also meets the expectations of the premium manufacturers we represent.
